Description
Your Ride. Your Choice.
All measurements provided in mm unless otherwise noted.
| M-4.60 | L-5.10 | |
| Rider heights | 170cm (5’7″) – 190cm (6’3″) | 180cm (5’11”) – 200cm (6’7″) |
| Wheel size | CST 29*2.1″ | CST 29*2.1″ |
| A-Seat tube | 460 | 510 |
| B-Seat tube angle | 75.5° | 75.5° |
| C-Head tube | 120 | 120 |
| D-Head angle | 70° | 71° |
| E-Top tube length | 622 | 662 |
| F-Standover height | 799 | 790 |
| G-BB drop | 65 | 65 |
| H-Rear Center | 475 | 475 |
| I-Wheelbase | 1178 | 1218 |
| J-Reach | 450 | 490 |
| K-Stack | 665 | 665 |
| L-Maximum seat height | 1020 | 1080 |
| M-Minimum seat height | 850 | 900 |
| N-Total length | 1943 | 1983 |
| O-Handlebar height | 1120 | 1120 |
| P-Handlebar length | 740 | 740 |
